Intelligent BMS Roj teeb Lifepo4 Kev Tiv Thaiv Kev Nyab Xeeb
2.Txhua lub roj teeb tau tsim nrog lub ntse BMS
Lub roj teeb rechargeable lifepo4 roj teeb pob muaj 15-xyoo kev pab cuam lub neej ntev li ntev tau ua haujlwm zoo. Los ntawm kev sib txuas nrog cov ntshiab sine yoj inverter, cov neeg siv tuaj yeem tswj hwm tag nrho lub hnub ci ntawm lub xov tooj ntawm tes daim ntawv thov thiab teeb tsa tus nqi & tso tawm hom remotely.
Cim lifepo4 roj teeb enclosure peb siv cov cuab yeej ntxeem tau, tsis tsuas yog kom txuag tau qhov hnyav tab sis kuj txo qhov kub hauv lub sijhawm luv luv. Lub neej ntev thiab txhim khu kev ntseeg tau
Parameter
|
TSIS MUAJ |
Qauv No. |
BP-HR-20KWH-B |
BP-HR-25-BKWH |
BP-HR-30KWH-B |
|
1 |
Rated Voltage |
51.2V |
51.2V |
51.2V |
|
2 |
Cell Combination Hom |
16S2P |
16S2P |
16S2P |
|
3 |
Rated Peev Xwm |
400 Aw |
4 56ah |
5 60ah |
|
4 |
Rated Zog |
PEB 20.48 KWh |
PEB 23.35 kWh |
28.67 kWh |
| 5 | Voltage Ntau | 40V-58.4V | 40V-58.4V | 40V-58.4V |
|
6 |
Lub voj voog (80% DOD) |
8000 cycles |
8000 cycles | 8000 cycles |
|
7 |
Qhov tob ntawm kev tso tawm |
80% |
80% | 80% |
|
10 |
Maximum Continuous Charge Current |
160A |
200A |
200A |
|
11 |
Maximum Continuous Discharge Current |
200A |
200A |
200A |
|
12 |
Qhov hnyav |
150 kg |
190kg ib |
230kg ua |
|
13 |
Qhov Loj L * W * D (mm) |
L720 * W450 * H600mm |
L740 * W450 * H650mm |
L740 * W450 * H680mm |
|
14 |
Hom roj teeb |
Lub log roj teeb |
||
|
15 |
Kev ua haujlwm kub |
Them nqi: 0℃~ 55 degree, Tawm: -10 ~ 55 degree |
||
| 16 | Cia Kub | Khaws ntawm 0℃rau 55 degree | ||
| 17 | Hom Cell | LiFePo4 Lithium ion Phosphates roj teeb | ||
| 18 | Kev tu | Kev kho dawb | ||
| 19 | Kev sib haum xeeb | Tau tshaj nrog rau feem ntau ntawm cov muaj tawm -gird/hybird inverters thiab them controllers | ||
| 20 | BMS | Intelligent roj teeb tswj system | ||
| 21 | Maximum Parallel/Moduler Connection | 16 pcs | ||
Khoom nta
1. Kov lub LCD kom nyeem cov ntaub ntawv roj teeb
2. Peb muab 10 xyoo warranty, txhua lub tsev tuaj yeem kav ntev txog 15 xyoo
3. Txiav-ntug thev naus laus zis roj teeb tuaj yeem txuas nrog cov inverter sib txawv
4. Txhawb RS232, CAN, thiab RS485 ntau yam kev sib txuas lus raws tu qauv
Dab tsi yog Cov Txheej Txheem Tseem Ceeb ntawm Intelligent BMS Roj Teeb LiFePO4 Kev Tiv Thaiv Kev Nyab Xeeb?
Lub Ntsej Muag BMS Roj Teeb LiFePO4 Kev Tiv Thaiv Kev Nyab Xeeb suav nrog cov ntsiab lus tseem ceeb xws li cov ntsuas hluav taws xob, ntsuas ntsuas kub, thiab cov tswj hwm tam sim no kom muaj kev ncaj ncees ntawm tes. Cov khoom siv no ua haujlwm sib koom ua ke los tiv thaiv kev sib txawv ntawm kev ua haujlwm tsis zoo, nrog rau LiFePO4 cov hlwb ua haujlwm ntawm 2.5V thiab 3.65V. Cov qauv zoo tshaj plaws suav nrog kev sib txuas Bluetooth rau kev kuaj mob nyob deb, tso cai rau cov neeg siv taug qab lub xeev -ntawm- nqi (SoC) thiab xeev- ntawm-kev noj qab haus huv (SoH) ntawm smartphone apps. Cov txiaj ntsig ntawm cov ntse BMS hauv LiFePO4 roj teeb rau kev nyab xeeb yog pom tseeb hauv lawv lub peev xwm los teb rau qhov tsis xws luag hauv microseconds, raws li tau sau tseg hauv kev tshawb fawb los ntawm American Chemical Society ntawm stretchable lithium technologies. Qhov kev teeb tsa no tsis yog tsuas yog txuas lub voj voog lub neej mus rau ntau dua 8,000 lub voj voog tab sis kuj txo qis kev pheej hmoo cuam tshuam nrog thermal khiav.
Txoj Cai Txhim Kho
Cov khoom siv hluav taws xob hnub ci yuav tsum muaj cov kws tshaj lij los txhim kho. Rau kev nyab xeeb, peb tsis pom zoo kom cov neeg siv khoom nruab hnub ci khoom lawv tus kheej tshwj tsis yog lawv yog cov kws tshaj lij.
Peb tuaj yeem muab kev txhawb nqa thaum lub sijhawm teeb tsa. Yog tias koj muaj lus nug, thov xa peb cov duab thiab cov yeeb yaj kiab rau kev sib txuas lus thiab kos. Peb yuav muab kev pabcuam online hauv lub sijhawm.
Khoom tsim nyog
Nruab
Ntim
Hais txog peb
FAQ
Q: Cov roj teeb puas siv tau?
A: Peb Cov Khoom Siv Hluav Taws Xob Hauv Tsev yog siv los ntawm lithium{0}}ion thev naus laus zis tshiab thiab tau tsim los nrog kev nyab xeeb tiag tiag hauv siab rau ob qho tib si hauv tsev thiab kev lag luam. Tsis muaj kev pheej hmoo ntawm kev tawg lossis hluav taws.
Q: Dab tsi ua rau koj lub roj teeb sib nrug ntawm cov uas muab los ntawm lwm tus neeg muag khoom?
A: Peb lub roj teeb paub txog nws cov yam ntxwv kev nyab xeeb thiab lub neej ntev, uas ua rau nws sib nrug los ntawm lwm tus neeg muab khoom.
Q: Koj lub roj teeb ua li cas kom muaj kev nyab xeeb dua piv rau lwm tus?
A: Peb cov roj teeb tau tsim los nrog kev nyab xeeb yog qhov tseem ceeb tshaj plaws, nrog cov thev naus laus zis tshiab tau koom ua ke los xyuas kom muaj kev tiv thaiv lub roj teeb ntawm overheating, overcharging, thiab tshaj - tso tawm.
